重切削车床

TNC530 / 530L

加入询价车

Capacity
Swing over Bed	530 mm (20.9＂)
Swing over cross slide	305 mm (9.4＂)
Center height	265 mm (10.4＂)
Distance between centers	1000 - 1500 mm (40”) - (60”)
Bed width	350mm (13.8＂)
Width of cross slide	220 mm (8.6＂)

Spindle speed / A1-6 or D1-6 (2")	35~1600 rpm
Carriage
Turret	H4 or V8
Tool size	H4: 25x25 mm, V8: 25x25 mm
X axis Travel	300 mm (11.8＂)
Z axis Travel	895 mm (35.2＂),1415 mm (55.7＂)
X axis rapid travel, Ball screw dia.	6M/min (Dia. 25mm)
Z axis rapid travel, Ball screw dia.	6M/min (Dia. 40mm)
Tailstock
Quill diameter	65 mm (2.5＂)
Quill travel	150 mm (6＂)
Quill taper	MT5
Motor
X axis servo motor	1.2 Kw
Z axis servo motor	1.2 Kw
Spindle motor	7.5 / 11 Kw
Lubricant pump motor	0.455 Kw
Coolant pump	1 Kw
Machine weight
1000 mm center distance	3000 kgs
1500 mm center distance	3500 kgs

※ 规格如有变更，恕不另行通知。

特性

半、全自动操作
全CNC控制操作
3 点式轴承支撑主轴箱、研磨、硬化处理齿轮。
米汉纳铸造技术FC-30 铸件
教导式CNC车床
