重切削車床

FB80N

加入詢價車

Capacity
Swing over Bed	2000 mm (78.74＂)
Swing over cross slide(Half length)	1510 mm (59.4＂)
Swing over cross slide(Full length)	1440 mm (56.6＂)
Center height	1000 mm (39.37＂)
Distance between centers	3000 - 12000 mm (120”) - (480”)
Bed width / Auxiliary guide	1345 mm (52.9＂) /1575 mm (62＂)
Spindle
Spindle speeds / A2-15(8")	5~400 rpm
Spindle speeds / A2-20(10")	4~300 rpm
Carriage
Turret	H4 or V8
Tool size	H4: 50x50 mm, V8: 32x32 mm
X/Z axis travel Standard(Half length) cross slide	720 mm (28.35＂) / 3000 - 12000mm (118.11＂~472.44＂)
X/Z axis travel Standard(Full length) cross slide	1250 mm (49.2＂) / 2600 - 11600mm (102.36＂~456.69＂)
X axis rapid travel, Ball screw dia.	5M / mindia. 50 mm (1:2 Gear Box)
Z axis rapid travel, Ball screw dia.	5M / min3-4M (dia. 80 mm), 5-6M (dia. 100 mm), 7-12M ( Rack and Pinion Driver)
Tailstock
Quill diameter	290 mm (11.4＂)
Quill travel	300 mm (11.8＂)
Quill taper	MT7
Motor
X axis servo motor	FANUC αiF22 4 kw
Z axis servo motor	FANUC αiF30 7.0 kw
Spindle motor	FANUC αiI 50 45 / 55 kw
Coolant pump	1 kw
Hydraulic pump	7.5 kw
Machine weight
3000 mm center distance	34500 kgs
Each extra 1000 mm weight	4500 kgs

※ 規格如有變更，恕不另行通知。

特性

強力箱型主軸箱
可程式自動換檔
主軸轉速可程式
高剛性四滑軌設計
特殊齒輪箱設計提供主軸低轉速高扭矩輸出
