高效精密CNC車床
MENU
| Capacity | |
|---|---|
| Swing over Bed | 660mm (25.9＂) |
| Swing over cross slide | 480mm (18.9＂) |
| Max. turning diameter | 500mm (19.6＂) |
| Working length | 2280mm (89.7＂) |
| Spindle | |
| Spindle nose | A2-8 / Opt. A2-11 |
| Spindle bore | Dia. 105mm (4.1＂) / Opt. 131mm (5.1＂), 165mm (6.5＂) |
| Bar capacity | Dia. 89mm (3.5＂) / Opt. 117mm (4.6), 142mm (5.6) |
| Max. spindle speed | 2500 rpm / Opt. 2000 , 1650 rpm |
| Spindle gearbox step | 2 |
| Turret | |
| Turret type | V10 / Opt. V12 |
| Tool size | 32mm (1.25＂) / Opt. 25mm (1＂) |
| ID Tool holder dia. | Dia. 50mm (2＂) |
| Tailstock | |
| Tailstock travel | 2160mm (85＂) |
| Quill stroke | 100mm (3.9＂) |
| Quill diameter | 110mm (4.3＂) |
| Taper of center | MT5 |
| Motor | |
| Spindle | 22 / 26 Kw |
| X / Z axis servo motor | 4 / 4 Kw |
| Coolant pump | 0.75 Kw |
| Hydraulic pump | 2.2 Kw |
| Hydraulic chuck size | Std. 12＂ / Opt. 15＂ |
| X / Z axis | |
| X axis travel | 250+25mm (9.84+1＂) |
| Z axis travel | 2380mm (93.7＂) |
| X / Z axis rapid travel | X: 12 M/min Z: 15 M/min |
| X / Z axis ball screw | Dia. 40mm x P6 / Dia. 63mm x P10 |
| Cutting feed rate | 0.001～500 mm/min |
| Dimension | |
| Machine dimension | 6824×2130×2235mm |
| Machine weight NW/GW | 13700 / 15700kgs |
※ 規格如有變更，恕不另行通知。
特性
最大切削直徑500mm
高剛性、重切削
45度斜床身結構，排屑方便
高剛性主軸最高轉速2500rpm
高剛性、重切削
45度斜床身結構，排屑方便
高剛性主軸最高轉速2500rpm
